zweidimensionales bewegtes Bild

Schneidzerkleinerung von Weich-PVC - Einzelschnitt

Einflußgrößen wie Spandicke und -höhe, messergeometrische Winkel, Schneidenabstand und Schnittgeschwindigkeit werden variiert. Ein aufgebrachtes Raster veranschaulicht die auftretende Verformung. Mit Zeitdehnung.
The film shows the cutting of soft polyvinylchloride (PVC) by means of a cutting apparatus operating in principle along the line of a cutter of the type used to cut continuous lengths of material into pieces of substantially uniform size. The parameters affecting the cutting operation are varied and include, along others, chip thickness and chip height, cutting angle and lip angle and the clearance angle reuslting from these two, the gap between the blade and counterblade, and the cutting speed. The deformation present in the material during the cutting operation is rendered visible by a grid pattern (raster) applied to the material prior to cutting. It is apparent from the shots that the cut shown is a knife-type cut within the range of the parameters investigated. Close-ups show the entry and severance processes.

Digitalisierung: Hannover TIB

Free access - no reuse

0
/
0

Alternative title
Cutting of Soft PVC - Single Cut
Location
Hannover TIB
Extent
67MB, 00:05:30:00 (unknown)
Notes
Audiovisuelles Material
Stummfilm
Silent movie

Bibliographic citation
Schneidzerkleinerung von Weich-PVC - Einzelschnitt ; (Jan. 1975)

Keyword
PVC / soft PVC
Fertigungstechnik
Encyclopaedia Cinematographica
Schneidzerkleinerung / Weich-PVC
Verfahrenstechnik
technology
soft PVC / cutting
spanende Bearbeitung
Polyvinylchlorid
mechanical procedures
Weich-PVC / Schneidzerkleinerung
PVC / Weich-PVC
polyvinyl chloride
production engineering
process engineering
Technik
swarf machining
cutting / soft PVC
Mechanische Verfahren

Event
Veröffentlichung
(who)
IWF (Göttingen)
(when)
1975-01-01
Contributor
Redeker, D.

DOI
10.3203/IWF/E-2019
Last update
04.12.2024, 8:09 AM CET

Data provider

This object is provided by:
Technische Informationsbibliothek (TIB). If you have any questions about the object, please contact the data provider.

Object type

  • zweidimensionales bewegtes Bild

Associated

  • Redeker, D.
  • IWF (Göttingen)

Time of origin

  • 1975-01-01
