Handzeichnung
Sportfield Kairo Tennis Stadium: Administration, Main Entrance, Restaurant, 2 Grundrisse Ground Floor, Upper Floor, 4 Ansichten South Elevation, North Elevation, East Elevation, West Elevation, 3 Schnitte Section A-B, Section C-D, S
- Standort
-
Architekturmuseum der Technischen Universität Berlin
- Inventarnummer
-
39510
- Maße
-
Blattmaß: 76,1 x 118,2 cm
- Material/Technik
-
Tusche und Bleistift auf Transparent
- Bezug (wo)
-
Kairo
- DOI
- Rechteinformation
-
Rechte vorbehalten: Architekturmuseum der TU Berlin, Inv. Nr. 39510. Das Werk ist urheberrechtlich geschützt, eine Nutzung des Digitalisats darf nur nach Autorisierung erfolgen.
- Letzte Aktualisierung
-
28.04.2025, 13:44 MESZ
Datenpartner
Dieses Objekt wird bereitgestellt von:
Architekturmuseum der Technischen Universität Berlin. Bei Fragen zum Objekt wenden Sie sich bitte an den Datenpartner.
Architekturmuseum der Technischen Universität Berlin. Bei Fragen zum Objekt wenden Sie sich bitte an den Datenpartner.
Objekttyp
- Handzeichnung
Beteiligte
Entstanden
- 1957-1958
